Power TVS

P600

Features
 8000 watts Peak Pulse Power (10/1000μs waveform)
 Unidirectional and Bidirectional Protection
 Fast Response Time :Typically < 1ns
 Excellent Clamping Capability
 Glass Passivated Junction
 Meets ISO7637-2 surge spec (varied by test condition)
 Plastic package has Underwriters Laboratory Flammability classification 94V-0
 High temperature soldering guaranteed:260°C /10 seconds/.375”,(9.5mm) lead length/5lbs.,(2.3kg) tension

Applications
 I/O Interfaces
 Power lines
 Automotive and Telecommunication
 Signal lines of sensor units for consumer
 Industrial Electronics
 Computer​
