CESD

WEPxxxRF0603

Features
 Ideal ESD protection for high frequency, high speed applications.
 Ultra-low capacitance (0.2pf typical ).
 Fast response time ( <1ns, 0.5ns typical ).
 Very low leakage current, reduces power consumption.
 Bi-directional device for placement flexibility.
 Surface mount design for board space savings.
 Compatible with standard reflow installation procedures.

Application
 High Speed Data Ports, DVI, HDMI1.3/1.4, USB2.0/3.0, DisplayPort1.0/1.1, e-SATA, IEEE1394.
 Antennas (Cell phone, Satellite Radio, GPS…), Blue Tooth, LED lighting Protection.
 Portable devices, Cellular phone, PDA’s, Digital Cameras, Digital Camcorders.
 High Speed Ethernet, DSL Modems, Computers & Peripherals, Printer ports.
 HDTV, Set Top Boxes, DVD Players, A/V Equipment, Multimedia Players.​
