Low Cap TVS

DFN3.8x1.0-9L

Features
 100 Watts peak pulse power (tp=8/20μs)
 Protects 8 high-speed IO channels
 Low capacitance：0.3pF typical
 Low leakage current
 Low operating and clamping voltage
 Solid-state silicon-avalanche TVS process technology

Applications
 High Definition Multi-Media Interface(HDMI)
 DisplayPort interface
 SATA and eSATA interface
 10/100,1000M Ethernet
 V-By-One
 LVDS interfaces​
